DS-TPE304-S Entrance & Exit Control Terminal with PMS
- Cascade management: One can manage up to 4 lanes, and up to 5 devices can be cascaded
- Strong adaptability: fully closed structure, no fan heat dissipation design, can be used at -10~50° working temperature
- Multi network interface design: 8 network interfaces on the internal network support the access of a large number of network devices and saving switch costs; 2 gigabit network port on the external network support network fault tolerance and dual network IP setting, dual network isolation and other applications
- Remote access: Supports Internet remote access to devices, remote troubleshooting, remote log download, and remote device upgrade
- Local display control: Support VGA/HDMI display, standard mouse and keyboard input control, plug and play, convenient and fast
- Standard SDK interface: The standard SDK protocol supports interconnecting with cloud platforms and has strong external scalability
- Huge pictures storage: 4T 3.5″ HDD and 128GB SSD
- Multi other interface: 2 RS-232, 1 RS-485, 2 alarm in, 2 alarm out, 4 USB, 1 audio in, 1 audio out
- Built-in Parking Management System software
- Description
Description
Terminal
- CPUJ6412, Elkhart Lake Platform Processor, 2 GHz
- Memory4 GB
- Storage3.5″ 4T Surveillance-Level HDD+ 128GB SSD
Interface
- Indicator4 Indicators (1 x System Indicator, 1 x Hard Disk Status Indicator, 1 x Power Indicator, 1 x Alarm Indicator)
- Audio1 x Audio Input (MIC IN)； 1 x Audio Output (AUDIO OUT)
- Video Output1 x HDMI, 1 x VGA
- Alarm Input2 x Alarm Input (ALARM IN)
- Alarm Output2 x Alarm Output (ALARM OUT)
- RS-2322 x RS-232 Interface
- RS-4851 x RS-485 Interface
- USB2 x USB 2.0 Interface, 2 x USB 3.0 Interface
- Network Interface8 x 10 Mpbs/100 Mpbs Self-Adaptive Interface, supporting connecting with switch; 1 x Independent 100 Mpbs/1000 Mpbs Self-Adaptive Interface, supporting network isolation
General
- MaterialBlack Aluminum Material
- Power Supply12V DC /5A
- Power ConsumptionMax.: 50 W Average: 25 W
- Working Temperature and Humidity-10 °C to 50 °C (14 °F to 122 °F); 10 % to 95% (No Condensation)
- Storage Temperature and Humidity-20 °C to 70 °C (-4 °F to 158 °F); 10 % to 95% (No Condensation)
- Dimensions245 × 170 × 65 mm (9.65 × 6.69 × 2.56 inch)
- Dimensions (with Package)450 × 240 × 105 mm (17.7 × 9.45 × 4.1 inch)
- 2 kg (4.4 lb.)
- Weight (with Package)2.5 kg (5.5 lb.)
