Face Recognition Terminal Kit – DS-KAS541

Description

Face Recognition Terminal/System parameters

• Model: DS-K1T341CMF
• Operating system: Linux

Face Recognition Terminal/Display parameters

• Screen size: 4.3-inch
• Operation method: Capacitive touch screen
• Type: LCD
• Resolution: 480 × 800

Face Recognition Terminal/Video parameters

• Lens: × 2
• Resolution: 2 MP

Face Recognition Terminal/Network

• Wired network: 10 M/100 M/1000 M self-adaptive

Face Recognition Terminal/Interface

• Network interface: 1
• Lock control: 1
• Exit button: 1
• Door contact input: 1
• TAMPER: 1
• RS-485: 1
• Wiegand:1
• USB: 1

Face Recognition Terminal/Capacity

• Face capacity: 1,500
• Fingerprint capacity: 1,500
• Card capacity: 1,500
• Event capacity: 150,000

Face Recognition Terminal/Authentication

• Face recognition distance: 0.3 to 1.5 m
• Face recognition accuracy rate: ＞99%
• Face recognition duration: ＜ 0.2 s
• Fingerprint recognition duration: ＜ 1 s
• Card type: M1 card
• Card reading frequency: 13.56MHz
• Card reading distance: 0 to 3 cm
• Card reading duration: ＜ 1 s

Face Recognition Terminal/Function

• QR code recognition: Support
• Face anti-spoofing: Support
• Audio prompt: Support
• Time synchronization: Support

Face Recognition Terminal/General

• Button: Touch screen
• Power supply: 12 VDC, 2 A.
• Working temperature: -30 °C to 60 °C (-22 °F to 140 °F)
• Working humidity: 0 to 90% (No condensing)
• Protective level: IP65
• Dimensions: 172.5 mm × 83.2 mm × 22.7 mm (6.79″ × 3.27″ × 0.89″)
• Installation: Surface mounting

Magnetic Lock/General

• Model: DS-K4H258S
• Unlock method: Current interruption
• Maximum holding force: 280 kg (617.4 Lbs) linear thrust
• Power supply: 12 VDC, 340 mA
• Indicator: Green (work status)
• Surface temperature: ≤ ambient temperature 20 °C (68 °F)
• Working temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Working humidity:0 to 95% (relative humidity)
• Dimensions

  Lock body: 238 mm × 45 mm × 25 mm (9.4″ × 1.8\” × 1.0\”)

  Armature plate: 182 mm × 38 mm × 12.5 mm (7.2 × 1.5\” × 0.5\”)”

• Weight: 2.1 kg (4.6 Lbs)
• Suitable door: Wooden door, glass door, metal door, fireproof door
• Shell performance: Hard anodizing electroplating operated
• Lock body: Eco-friendly Nickel electroplating operated
• Armature plate: Eco-friendly Nickel electroplating operated

Card/General

• Model: FM11RF08-M1
• RAM: 1 K byte
• Card reading frequency: 13.56 MHz
• Card property: Thin card
• Function: Read/write
• Card reading distance: ≤10 cm
• Working temperature: -20 °C to 75 °C (-4 °F to 167 °F)
• Dimensions: 85.5 mm × 54 mm × 0.8 mm (3.37″× 2.13″ × 0.03″)
• Weight: ＜ 5.6 g (0.2 oz)
• Material: PVC
• Color: White

Bracket of Magnetic  Lock/General

• Dimensions

  L-bracket: 238 mm ×30 mm × 47 mm (9.4″ × 1.2\” × 1.9\”)

  Z-bracket: 185 mm ×44mm × 100 mm (7.3 ×1.7\” × 3.9\”)”

• Model: DS-K4H258-LZ
• Suitable Door: Wooden, metal
• Shell performance: Hard anodizing electroplated
• Weight: 0.77 kg (1.7 lb.)

Exit Button/General

• Model: DS-K7P03
• Power supply: 12 VDC, 40 mA (standby)/70 mA (working)
• Current rating: 1 A@30 VDC
• Working temperature: -20 °C to 50 °C (-4 °F to 122 °F)
• Working humidity: 0 to 95% (relative humidity)
• Dimensions: 86 mm × 86 mm × 25.7 mm (3.39″ × 3.39″ × 1.01″)
• Weight: 0.2 kg (0.44 lb.)
• Material: Stainless steel
• Output contact: NO/NC/COM contact
• Aging test: Already passed 1 million times aging test
• Suitable door: All kinds of narrow doorframes
