Value Series Face Access Terminal – DS-K1T342MFX
- Max.1500 faces capacity, Max.3000 fingerprints capacity, and Max.3000 cards
- Face Recognition Terminal, 4.3-inch LCD touch screen,2 megapixel wide-angle lens, Built-in M1 card reading module
- Two-way audio with client software, indoor station, and main station; Supports TCP/IP
- Supports ISAPI, ISUP5.0
- Configuration via the web client
- Face Recognition Distance: 0.3 m to 1.5 m
- Duration ＜ 0.2 s/User
- Accuracy rate ≥ 99%
- Supports mask recognition
- Description
Description
System
- Operating system: Linux
Display
- Dimensions: 4.3-inch
- Resolution: 272 × 480
- Type: LCD
- Operation method: Capacitive touch screen
Video
- Pixel: 2 MP
- Lens: × 2
- Video standard: PAL (Default) and NTSC
Network
- Wired network: 10 M/100 M self-adaptive
- Wi-Fi: Support
Interface
- PoE: IEEE802.3at, standard PoE
- Network interface: 1
- RS-4851
- Wiegand: 1
- Lock output: 1
- Exit button: 1
- Door contact input: 1
- TAMPER: 1
- USB: 1
Capacity
- Card capacity: 3,000
- Face capacity: 1,500
- Fingerprint capacity: 3,000
- Event capacity: 150,000
Authentication
- Card type: M1 card
- Card reading frequency: 13.56 MHz
- Face recognition duration: ＜ 0.2 s
- Face recognition accuracy rate＞99%
- Face recognition distance: 0.3 to 1.5 m
- Fingerprint recognition duration＜1 s
General
- Power supply
Power input: Power interface (power adapter included, 12 VDC/1 A) or PoE (37 to 57 VDC/0.6 A)
Power output: Power supply for door lock, 12 VDC/1 A (only when the device is powered by PoE supporting powering supply for door lock)
- Working temperature: -30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity: 0 to 90% (No condensing)
- Dimensions91.3 mm × 181.3 mm × 24.5 mm (3.59″ × 7.14″ × 0.96″)
- Installation: Wall Mounting
- Protective level: IP65
- Language: English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean
- Weight
Gross weight: 0.93 kg (2.05 lbs)
Net weight: 0.36 kg (0.79 lbs)
Function
- Face anti-spoofing: Support
- Audio prompt: Support
- Time synchronization: Support
